Багер гасеничар Kubota kx155-5

Detailed Specifications Breakdown
Engine
• Model: Kubota D1803-CR-E4
• Type: 4-Cylinder, Liquid-Cooled, Diesel
• Displacement: 1.8 L (112 cu in)
• Power: 35.8 kW (48.0 HP) @ 2200 rpm
• Emission Standard: Tier 4 Final (without a DPF - Diesel Particulate Filter). Kubota achieved this through an advanced EGR (Exhaust Gas Recirculation) and DOC (Diesel Oxidation Catalyst) system, which is a significant selling point for this model.
Weights and Dimensions
• Operating Weight: 3,850 kg (8,488 lb) - This is the typical weight with a standard bucket and cab.
• Transport Length: 4,770 mm (15 ft 8 in)
• Transport Width: 1,990 mm (6 ft 6 in) - With standard 400mm (16 in) shoes.
• Transport Height: 2,710 mm (8 ft 11 in) - To the top of the cab.
• Ground Clearance: 380 mm (15 in)
• Tail Swing Radius: 1,550 mm (5 ft 1 in) - This is a Zero Tail Swing (ZTS) design, meaning the rear counterweight stays within the track width when rotating, allowing it to work flush against walls and in confined spaces.
Undercarriage
• Shoe Width: Standard 400 mm (16 in). Other widths were often available as options.
• Track Gauge: 1,590 mm (5 ft 3 in)
• Track Length: 2,570 mm (8 ft 5 in)
Performance
• Max Digging Depth: 4,110 mm (13 ft 6 in)
• Max Vertical Digging Depth: 3,660 mm (12 ft 0 in)
• Max Reach at Ground Level: 6,350 mm (20 ft 10 in)
• Max Loading Height: 5,210 mm (17 ft 1 in)
• Max Dump Height: 3,760 mm (12 ft 4 in)
• Digging Force (Bucket): 32.7 kN (7,351 lbf)
• Digging Force (Arm): 22.6 kN (5,081 lbf)
• Swing Speed: 11.5 rpm
• Travel Speed:
◦ High: 4.5 km/h (2.8 mph)
◦ Low: 2.8 km/h (1.7 mph)
• Gradeability: 30° (58%)
Hydraulic System
• Main Pump Type: Variable displacement axial piston pump x 2
• Total Flow: 2 x 72.0 L/min (2 x 19.0 US gpm)
• Relief Valve Pressure: 31.4 MPa (4,555 psi)
• Pilot Pressure: 3.4 MPa (493 psi)
Capacities
• Fuel Tank: 68 L (18 US gal)
• Hydraulic Oil: 85 L (22.5 US gal) - Total system capacity.
• Coolant: 9.5 L (2.5 US gal)
